Automatic Stormwater Drainage Pump RDP150

This automatic stormwater drainage pump is a commercial quality heavy duty pump that can lift water up to 14m and pump water up to 900 Litre/per min or 15 Liter/sec depending on the head. These drainage pump are for emptying clean water or storm water with particle sizes of 20mm.

REEFE® RDP Series drainage pumps are a HIGH FLOW industrial pump and are ideal for drainage of liquids with small solids in suspension. Clean water or ‘storm’ water containing only small soft solids is ideal for these pumps. These submersible pumps are designed to pump semi-screened clean water with ease.  The screen at the bottom of the pump will filter out any leaves, preventing them from entering the pump.

Model Number = RDP150
Max Flow = 900LPM
Max Head = 14m
Power = 240V single phase
Outlet = 80mm / 3.25 ”
Particle Size = 20mm
Warranty = 1 Year

Complete pumping systems such as pump, controller, tanks etc can be custom made.

This model can also be used in our 180L Stormwater Drainage Systems.

Please contact me for a quote.

Applications
• Stormwater drainage
• Shopping Centers
• Commercial Building
• Domestic Use
• Basement Car Parks
• Industrial Processes
• Flood Control

Features

• Thermal Overload Protection
• Electrical Safety Approval to AS / NZS 60335.2.41
• Dual Mechanical Silicon Carbide Seal in Oil Bath (RDP075 single seal)
• SS grade 304 multi-vane semi open impeller
• Auto Coupling kits available for larger models
• MAC 3 Italian made float switch on selected models
• H07RN-F 10m Cable
• Ingress Protection IP68
• Insulation Class F
