Rule-Mate 1100GPH Automatic Submersible Bilge Pump

The Rule-Mate 12V 1100GPH Automatic Submersible Bilge Pump has Rule’s exclusive “Spongeability” feature. It is an all-in-one bilge pump and switch with no float switch required.  The innovative design incorporates the bilge pump and water sensor in a single housing.

The unique Rule “Spongeability” feature leaves the bilge the driest ever – when water in the bilge reaches a certain height the solid state sensor automatically activates and the pump runs until the water is pumped out, reducing boat weight, saving fuel and minimizing bilge odour.

Pump check feature – simply touch the pump check button on the pump and hold for a few seconds to test cycle the pump.

The Rule-Mate 12V 1100GPH Automatic Submersible Bilge Pump has a threaded discharge port with O ring seal and are supplied with both 90 degree and straight hose ports – 20mm for 500 & 800 GPH – 28mm for 1100 GPH model.

Available in 12 volt or 24 volt (1100 only).

• Fully automatic all-in-one submersible bilge pump systems
• No separate float switch required
• Bilge water sensor and pump in one common housing
• Pump and sensor are internally common wired for easy installation
• No battery drain other than when the pump is in use
• Removable strainer and impeller area are accessible to clear debris
• Threaded discharge ports for easy installation
• 1 each straight and 90 degree hose ports supplied with the pump
• A 3rd wire allows for manual over-ride using a Rule switch panel (see below – RWB23 or 107  12volt,  RWB24 or 5188  24volt)  or it can activate an alarm or indicator lamp if desired
• Thermal overload protection
• Single touch pump check test button feature
• 3 different capacities 500 – 800 – 1100 gallons per hour
• 3 year limited warranty

All pumps are oval shaped – base footprint size : 110mm x 70mm.

1100 GPH 69 LPM 12 volt 3.8 amp

Fuse size 7.5 amp

Supplied with 2 x straight hose outlets -1 x 25mm (1?) & 28mm (1 1/8?)

Rule bilge pump control panels – These Rule 3 way control panels can be used to control and indicate operation of all Rule bilge pumps and will allow the Rule-Mate pumps to function with a manual over-ride operation feature using the 3rd wire supplied in the wiring harness of the pump.

The control panel options are: RWB23 12 volt or RWB24 24 volt, RWB107 12 volt or RWB5188 24 volt
