$4,687.00 Original price was: $4,687.00.$4,320.00Current price is: $4,320.00.
70 LPM @ 82m head -Variable Speed Bore Pump Kit
Use a Subdrive Constant Pressure Pump Kit when you need to pump water directly from the bore to the house or/and irrigation system.
The pump speed adjusts to the amount of taps that are turned on. SubDrive controllers are a complete bore pump kit which provide constant pressure by continually monitoring and adjusting the pump speed to meet water demands.
The Subdrive is a variable frequency drive constant pressure system.
All SubDrive Connect 1100 QuickPAKS include:
1 x SubDrive Pump, 1 x SubDrive motor, 1 x SubDrive Connect 1100 Controller in IP54 enclosure, 1 x Pressure gauge, 1 x Pressure sensor, 1 x 4” Splice kit, 1 x 18 litre pressure tank ,1 x bore cap and 1 x Manifold. All in one easy and quick package to get you pumping quickly!
SubDrive also eliminates pressure fluctuations during long running applications such as reticulation / irrigation systems and other domestic and industrial uses.
Features and Benefits
Constant water pressure with a wide range of settings (172 to 550 kPa)
Soft start feature prevents water hammer and increases motor life
Works with small pressure tanks or with larger tanks already in place
Smart Reset® technology allows well recovery before restarting the pump
Single-phase input power with three-phase motor performance
Excellent radio frequency interference shielding
Brand | Franklin Electric |
---|---|
litres-per-minute | 70 |
Outlet-size | 1 1/4" |
m3hour | 4 |
Model-number | SDQP1100-70.82 |
Warranty-period | 3 Years |
