Automatic Draining Pump – RVC260

The RVC Series of automatic draining pump is a submersible vortex pump specifically designed for sump, storm water and grey water pump out applications.

European made, this exceptional quality pump is ideal for integration into wastewater treatment systems, stormwater pits and grey water installations.

Featuring a compact, lightweight construction for fast installation.

A superior impeller design with soft solids handling up to 30mm.

Model Number = RVC260
Rated Flow = 140LPM
Rated Head = 5.6m
Max Flow = 280LPM
Max Head = 10.5m
Outlet = 32mm / 1.25″
Particle Size = 30mm
Weight = 8kg
Cable Length = 10m
L x W x H = 128 x 202 x 335
Amps = 3.3
Warranty = 2 Years

Automatic draining pump uses

Also commonly used for dirty water transfer, grey water, household waste water, sump draining, storm water drainage, pool emptying, sullage pumping and waste water system.

Features and Benefits:

• Compact design for faster and easier installation
• Soft solids handling up to 30mm
• 10m H07RN-F Power Cable
• Easily adjustable float switch guaranteeing better, faster and easier installation
• Manual overload protection reset

Construction:

• Stainless steel motor casing, pump body and shaft
• Cast iron vortex impeller
• G25 Cast iron base and motor cover
• Dual silicon/carbide, silicon/carbide mechanical seal
• European adjustable depth float switch
• Motor insulation Class F
