Automatic Sewage Grinder Pump

RGS11A automatic sewage grinder pump is another safe, dependable, trouble free I-Series pump. With the superior engineering, these are the tough Sewage Grinder pumps, suitable for the most demanding applications. The grinder mechanism provides an extremely powerful slicing action with more than 80,000 slicing actions per minute while the radical cutter and cutter ring reduces the torque and kilowatt requirements, which makes it one of the most efficient grinder pumps available.

The RGS11A automatic sewage grinder pump is commonly used in our packaged pump stations where effluent including raw sewage from a public venue needs to be pumped from an underground tank uphill to the septic system.

Model Number = RGS11A
Power = 240v
Max Flow = 189LPM
Max Head = 16m
Outlet = 32mm / 1.25″
Warranty = 1 Year

Guiderails are available but not included as length varies depending on well size

Applications

• Childcare Centres
• Recreational Facilities
• Waste Treatment Facilities
• Industrial Plants
• Sewage
• Schools

Features & Benefits

• Comes with 10 meters of cable
• Grinder mechanism composed of a fixed shredder ring and a rotating grinder made by
• hard Chromium-Molybdenum alloy
• Unique epoxy cable sealing base prevents water vapor entering the motor.
• Triplex seals – double mechanical seal plus an oil seal to isolate the motor from the sewage
• Lifting lugs for easy installation

 Construction

• Abrasion resistant construction
• Removable solid cast iron base
