Max Flow = 160LPM. Max Head = 10m. Automatic 0.55kw
A small sewage grinder pump from our Reefe range of grinder pumps. The new RGM055A is the automatic model with an automatic float switch. This macerator pump is perfect for smaller projects with short pipe runs. Fits well in small pits and pump stations. It may only be 0.55kw but this pump can grind anything that the Reefe Industrial RGS series can. It has all of the strength and quality construction that you expect from the REEFE commercial grinder pumps. With the benefit of a compact design and efficient operation this grinder fits where other grinder pumps won’t.
This model is commonly used in small pump stations where there is not enough fall from the house, granny flat, shed, etc, to the septic tank or sewage line. You will also find them being used for childcare centres, schools, recreational facilities, waste treatment facilities, industrial plants and sewage applications.
The main feature of this small grinder pump is it’s compact size making them ideal for narrow pits and sumps. It is also lightweight and portable. The pump can handle liquid temperatures of o to 40 degrees celcius and a PH range of 6-8.
The anti-clogging impeller design and abrasion resistant construction puts it right up there with the industrial grinders. Motor IP Rating is 68.
Note: Auto coupling kits are not available with this model.
Model Number = RGM055A
Max Flow = 2.6 LPSec
Max Head = 10m
Outlet = 32mm / 1.25″
AMPS = 3
Warranty = 1 Year
Dimensions = L 175mm x W 210mm x H 335mm
This automatic sewage grinder pump is commonly used in our smaller packaged pump stations.
Pump stations are used to pump effluent (including raw sewage from a public venue) from underground tanks uphill to the septic system or sewage line.
