4-6 Taps. 66LPM@49m head. Max Flow = 102LPM. Max Head = 58m
Variable-frequency constant pressure pumps, adopt the latest in VVVF (variable voltage and variable frequency) AC frequency conversion and speed regulation technology. These high quality pumps also boast the latest pressure sensing technology, through the feedback of real-time pressure sensing (as compared to the preset pressure), which means the controller can adjust the motor speed and maintain constant outlet pressure, even with fluctuating demand.
Model Number = VSRM58-102
Rated Flow = 66LPM @ 49m head
Max Flow = 102LPM
Max Head = 58m
Inlet / Outlet = 32mm
Taps = 4-6
Warranty = 2 Years
Features & Benefits
1) This pump is not suitable for suction lift applications. Use with above ground tanks only, the pump must have flooded suction.
2) The suction pipe must be of same or larger size than the pump inlet.
3) A swing check valve must be included in the suction pipework.
4) Other important conditions of warranty are in the instruction manual, read and follow the instructions prior to installation.
PRESSURE SETTING NOTES:
1.3 / 1.74
